Essential precautions to ensure safe usage and installation.
CAUTION: Never pull the appliance by the oven handle.
Avoid that children push the oven door - risk of tilting
Fix the appliance to the wall - risk of tilting
"ATTENTION!
Keep the oven door open when lighting the oven burner or the grill burner."
"ATTENTION!
THIS APPLIANCE MUST BE INSTALLED IN ACCORDANCE WITH APPLICABLE REGULATIONS AND ONLY USED IN A WELL-VENTILATED ROOM. BEFORE INSTALLATION AND USE CONSULT THE INSTRUCTIONS FOR USE."
Catalytic cleaning: A special oven coating lets you burn away grease and fat by running the oven at a high temperature.
Ignition: Electric cooking zone igniton by turning the control knob.
Residual heat indicators: Show when the hob surface is still hot after use.
Safety with thermocouples, if the flame fails gas is cut off automatically.
Gas oven & gas hob.
Cooling fan: The cooling fan starts automatically when the oven is switched on. It cools the electronic components and the external parts of the oven.
Performance
Cavity Size (L): 83
Cavity Size, Second Cavity (L): 36
Cleaning: Catalytic
Hob Type: Gas hob
Functions (Main Oven): Bottom heat
Functions (Second Oven): Bottom heat, Grilling
Cleaning (Second Oven): Catalytic
Right Front - Power/Diameter: 950W/66mm
Right Rear - Power/Diameter: 1900W/80mm
Left Front - Power/Diameter: 3400W/128mm
Left Rear - Power/Diameter: 1900W/80mm
Front Middle - Power/Diameter: No
Rear Middle - Power/Diameter: No
Installation
Recommended fuse (A): 10
Voltage (V): 240
Total Electricity Loading (W): 2400
Cord Length (m): 1.6
Colour: Stainless steel
Energy
Energy Rating: A
Main Oven Conventional Mode - Energy consumption per cycle (Kwh): 1.79
Second Oven Conventional Mode - Energy consumption per cycle (Kwh): 1.35
Other
Product Number (PNC): 948 905 189
Dimensions: 899-917x600x600
Main Oven - Trays Included: 1 Dripping pan black enamel
Second Oven - Trays Included: No
Main Oven - Shelves Included: 2 Flat shelf chromed wirework
Second Oven - Shelves Included: 1 Flat shelf chromed wirework, 1 Grill pan grid chromed wirework
Main Oven - Shelf Support: Grid Runners
Second Oven - Shelf Support: Grid runners
Gas Supply: Natural Gas: G20 (2H) 20 mbar
Expect spotless with a self-cleaning oven
The Catalytic Cleaning feature prevents dirt and grease from building up in the oven. This self-cleaning technology automatically activates when the temperature reaches 250C and removes cooking residue. No scrubbing, just a spotless oven.
Timed cooking results
To assure that you dishes are not overcooked, this cooker has an integrated timer with a minute minder function to alert you when your dishes are ready
Ignite. Sear. Serve.Quick cooking with gas
Expect fast results with the gas hob on the freestanding cooker. It provides powerful, highly responsive heating. So pots and pans are ready to cook with as soon as the flame is ignited. Meaning less waiting, and more focus on finessing flavours.
Delicious results with our oven and grill
Enjoy flexible cooking using our gas oven with electrical grill. It lets you produce dishes that wouldn’t be achievable in a simple gas oven. Unleash your creativity and create golden gratins, crispy lasagnes and crunchy crumble toppings in our oven.
XXL Capacity. More room. Better visibility
This advanced oven has a generous XXL Capacity cavity and full glass door for outstanding visibility.
